Description:
The Sony FCB-EX985EP block camera combines superb picture quality with high zoom capabilities, up to 336x with optical zoom. Ideally suited for IP-ready monitoring applications, the Sony FCB-EX985EP incorporates ¼-type SuperHAD II CCD with Interlace Scan with a digital output (ITU-R BT656). In addition, the Sony FCB-EX985EP features StableZoom Image Stabilization and Sodium Vapor Lamp Mode to reduce the yellowing of images. Additional color enhancement features are ideally suited for low vision applications.
The SONY FCB-EX985EP Camera SPECIFICATIONS:
Camera Specifications:
* Image Device: 1/4-type SuperHAD II CCD (interlace Scan)
* Effective Pixels: 380,000
* Digital Zoom: 12x (336x with optical zoom)
* Horizontal Viewing Angle: 55.8กใ (wide end) ~ 2.1กใ (tele end)
* Minimum Object Distance: 10 mm* (wide) ~ 1500 mm (tele) *Default: 290 mm
* Sync System: Internal/External (V-lock)
* Electronic Shutter: 1/1 to 1/10,000 s, 22 steps
* White Balance: Auto, ATW, Indoor, Outdoor Auto, Sodium Vapor Lamp (fix/auto), One-push, Manual
* Gain: Auto/Manual / Max. Gain Limit (-3 to 28 dB, 2 dB steps)
* Privacy Zone Masking: Spherical
* Character Generator: Title display (20 characters/line, 11 lines)
* Focus System: Auto (Sensitivity: normal, low), One-push AF, Manual, Infinity, Interval AF, Zoom trigger AF, Focus Compensation in ICR on
* Picture Effects: E-Flip, Nega Art, Black & White, Mirror Image, Color
Sony FCB-EX985EP Video Output Specifications:
* Lens Value: 28x optical zoom (F=3.5mm (wide) ~ 98.0 mm (tele)
* S/N Ratio: More than 50 dB
* Minimum Illumination: 0.3 lx (typical) (F1.35, 50 IRE)
* Video Output: Analog: VBS: 1.0 Vp-p (sync negative, Y/C; Digital: Y/Cb/Cr 4:2:2 (ITU-BT656 Style)
* Signal System: NTSC (FCBEX985E/FCB-EX985E), PAL (FCBEX985EP/FCB-EX985EP)
* Horizontal Resolution: 559 TV Lines
Sony FCB-EX985EP Interfaces Specifications:
* Camera Control Interface: VISCA (TTL signal level) Baud Rate: 9.6kb/s, 19.2Kb/s, 38.4Kb/s; Stop bit: 1/2 bit selectable
Sony FCB-EX985EP General Specifications:
* Dimensions (W x H x D): 50.0 x 57.5 x 88.5 mm
* Weight: 230 g
* Operating Temperature: -5กใ C ~ 60กใ
* Storage Temperature: -40กใ C ~ 60กใ C
* Power Consumption: 22.6 W (motors active: 4.4 W)
* Power Requirements: 6.0 V ~ 12.0 V DC |
