| MODE NO. |
MTV-64G22HN-ICR |
MTV-64G22HP-ICR |
| TV SYSTEM |
NTSC |
PAL |
| IMAGE SENSOR |
1/4-inch CCD Image Sensor |
| CCD TOTAL PIXELS |
~ 410K |
~ 470K |
| SCANNING SYSTEM |
525 lines, 60 fields/sec |
625 lines, 50 fields/sec |
| SYNC SYSTEM |
Internal / VD-Lock |
| MINIMUM ILLUMINATION |
Typical |
1.5 Lux F1.6 |
1.5 Lux F1.6 |
| Star light Mode |
0.05 Lux F1.6 |
0.05 Lux F1.6 |
| RESOLUTION |
520 TVL |
520TVL |
| S / N RATIO |
48dB ( MIN ) / 52dB ( TYP ) (AGC OFF£¬r=1£¬APC OFF£¬Y-OUT) |
| DNR (Digital Noise Reduce) |
S/N UP 4.5dB |
| WHITE BALANCE |
ATW / AWC / FIX |
| WHITE BALANCE RANGE |
3200 ~ 9600 ºK |
| B.L.C. FUNCTION |
Super BLC,48 zone BLC |
| GAMMA CORRECTION |
0.45 /1 |
| AGC |
AUTO (24dB max) |
| ALC |
AUTO / FIX |
| IMAGE NEGATIVE |
Select by OSD menu |
| MONTION DETECT |
48 zone (select by OSD) |
| FREEZE FUNCTION |
Alarm in trigger or Select by OSD |
|
CROSS LINE |
ON/OFF Select by OSD menu (position adj. by software) |
| ELECTRONIC SHUTTER |
AES : 1/60(1/50) ~ 1/120,000 sec. / MANUAL : 8 step |
| LENS |
22X optical ZOOM LENS ,F1.6~3.8,f=3.9~85.8mm |
| ZOOM |
220X (22X optical 10Xdigital) |
| FOCUS |
Auto / Manual |
| POSITION |
64 Position (Zoom£¬Focus) |
| ICR (IR-CUT REMOVEABLE) |
AUTO/MANUAL |
| VIDEO OUTPUT |
Composite & Y/C output 1.0Vp-p at 75 ohm |
| CONTROL FUNCTION |
OSD control ,Dry Switch , RS-232C/RS-485(option) |
| OSD LANGUAGE SELECT |
ENGLISH / CHINESS_Simp / JAPANESE |
| OPERATION TEMPERATURE |
-10¡æ TO 50¡æ |
| OPERATIONAL HUMIDITY |
within 85©‡RH |
|
POWER SUPPLY |
DC12V¡À1V / 4W(Max) |
